Onyx Ultra Slim Medical PC With Intel ...

Onyx - Ultra Slim Medical PC With Intel Alder Lake-N | MEDPC-3300

Supplier: Micromax

Ultra Slim Medical PC With Intel Alder Lake-N | MEDPC-3300

Introducing the Onyx Ultra Slim Medical PC MEDPC-3300 with Intel Alder Lake-N. Experience powerful performance in a compact design, perfect for healthcare environments. Enhance efficiency and patient care today!

Features

Intel® Alder Lake-N i3-N305 / N97
DDR5 4800MHz SO-DIMM up to 32GB
2x USB 3.2, 4x USB 2.0, 2x LAN, 2x HDMI 2.0b
Supports TPM 2.0
Digital IO (8-bit GPIO) (optional)
4K capture card (optional)
2x COM (optional)
External power switch (optional)

Specifications

Main Specifications
Processor	Intel® Alder Lake-N series i3-N305 / N97
System Memory	DDR5 up to 32GB
Graphics	Intel® UHD Graphics
Storage	M.2 SSD up to 1TB
Wireless Communication	WiFi 6E + BT 5.3 (optional)
Speaker	2x 3W (optional)
Trusted Platform Module	TPM 2.0
OS Support	Microsoft® Windows 11 (64-bit) Ubuntu 24.04 LTS IGEL 11 / 12 (thin client solution)
I/O
Rear I/O	1x 12V DC-in power jack (DCIN1) 1x USB 3.2 (Gen 2) Type-A port 1x USB 3.2 (Gen 2) Type-C port 4x USB 2.0 port 2x HDMI 2.0b 2x 2.5Gbps RJ-45 LAN port 1x audio line-out / mic port 1x ground pin 1x K-slot 1x digital IO (optional) 2x COM (optional) 1x capture port, HDMI (optional), works with SATA III only
Front I/O	1x power key with LED 1x external 4-pin power switch (optional) 1x storage LED indicator
Mechanical and Environmental
Operating Temperature	0°C ~ 35°C (32°F ~ 95°F)
Storage Temperature	-20°C ~ 60°C (-4°F ~ 140°F)
Dimension	180 x 133 x 60 mm
Net Weight	1.2 kg
Package Size	305 x 225 x 230 mm
Gross Weight	2.4 kg (5.28 lb)
Certifications	CE: EN 60601-1-2:2015 + A1:2021 (V4.1), EN 60601-1:2007 + A1:2013 + A2:2021 (V3.2) EN 55032:2015/A1:2020 EN 55035:2017/A11:2020 (ITE) IEC 62368-1:2020+A11:2020 (ITE) FCC: Part 15B / Part 18 UL: ANSI AAMI ES60601-1:2005/A1:2012/A2:2021 (V3.2) cUL: CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020, MOD) (V3.2)

To contact Micromax about Onyx Ultra Slim Medical PC With Intel Alder Lake-N | MEDPC-3300 use Get a quote.

Features

Intel® Alder Lake-N i3-N305 / N97
DDR5 4800MHz SO-DIMM up to 32GB
2x USB 3.2, 4x USB 2.0, 2x LAN, 2x HDMI 2.0b
Supports TPM 2.0
Digital IO (8-bit GPIO) (optional)
4K capture card (optional)
2x COM (optional)
External power switch (optional)

Specifications

Main Specifications
Processor	Intel® Alder Lake-N series i3-N305 / N97
System Memory	DDR5 up to 32GB
Graphics	Intel® UHD Graphics
Storage	M.2 SSD up to 1TB
Wireless Communication	WiFi 6E + BT 5.3 (optional)
Speaker	2x 3W (optional)
Trusted Platform Module	TPM 2.0
OS Support	Microsoft® Windows 11 (64-bit) Ubuntu 24.04 LTS IGEL 11 / 12 (thin client solution)
I/O
Rear I/O	1x 12V DC-in power jack (DCIN1) 1x USB 3.2 (Gen 2) Type-A port 1x USB 3.2 (Gen 2) Type-C port 4x USB 2.0 port 2x HDMI 2.0b 2x 2.5Gbps RJ-45 LAN port 1x audio line-out / mic port 1x ground pin 1x K-slot 1x digital IO (optional) 2x COM (optional) 1x capture port, HDMI (optional), works with SATA III only
Front I/O	1x power key with LED 1x external 4-pin power switch (optional) 1x storage LED indicator
Mechanical and Environmental
Operating Temperature	0°C ~ 35°C (32°F ~ 95°F)
Storage Temperature	-20°C ~ 60°C (-4°F ~ 140°F)
Dimension	180 x 133 x 60 mm
Net Weight	1.2 kg
Package Size	305 x 225 x 230 mm
Gross Weight	2.4 kg (5.28 lb)
Certifications	CE: EN 60601-1-2:2015 + A1:2021 (V4.1), EN 60601-1:2007 + A1:2013 + A2:2021 (V3.2) EN 55032:2015/A1:2020 EN 55035:2017/A11:2020 (ITE) IEC 62368-1:2020+A11:2020 (ITE) FCC: Part 15B / Part 18 UL: ANSI AAMI ES60601-1:2005/A1:2012/A2:2021 (V3.2) cUL: CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020, MOD) (V3.2)

Read less...

To contact Micromax about Onyx Ultra Slim Medical PC With Intel Alder Lake-N | MEDPC-3300 use Get a quote.

Datasheet(0.29MB)
