Onyx 27" Slim 4k Medical Display | MEDDP-727 ...

Onyx - 27" Slim 4k Medical Display | MEDDP-727

Supplier: Micromax

27" Slim 4k Medical Display | MEDDP-727

27" Slim 4K Medical Display, High Brightness 500nits, Compact and Slim Design, 10W Speaker built-in x 2, Physical OSD key button, RFID, Camera, DICOM

Features

27" LCD panel with 3840 x 2160 resolution
High brightness 500 nits
Compact and slim design
DVI-D x 1, HDMI 2.0 x 1, DP 1.2 x 1, VGA x 1, HD-SDI in x 1 and out x 1
True flat screen with capacitive touch
10W built-in speaker x 2
Physical OSD key button
Supports optional RFID, camera and DICOM
8MP camera and microphone (optional)

Specifications

Display
Size	27"
Resolution	UHD 3840 x 2160
Max. Colors	1.07B colours
White Luminance (typ.)	500 nits
Viewing Angle (CR=10) (typ.)	178° (H) / 178° (V)
Contrast Ratio (typ.)	1000:1
Touch Screen	Projected capacitive multi-touch screen
Power Requirement	External power adapter, AC in 100~240V, DC 12V / 7.5A
System
OS Support	Windows® 10, Windows® 11
I/O
Input Signal	DVI-D x 1, HDMI 2.0 x 1, DP 1.2 x 1, VGA x 1, HD-SDI x 1
Output Signal	HD-SDI x 1
USB Port	USB 3.0 Type B x 1 for touch screen USB 3.0 Type A x 1 for USB peripherals
Audio	Line-in x 1
Speaker	Built-in 10W speaker x 2
Mechanical and Environmental
Operating Temperature	5°C ~ 40°C (41°F ~ 104°F)
Storage Temperature	-10°C ~ 60°C (14°F ~ 140°F)
Storage Humidity	10% to 90% RH, non-condensing
VESA	100 x 200 mm, 100 x 100 mm
Dimension (W/H/D)	657 x 400 x 62 mm
Packing Size (W/H/D)	786 x 537 x 232 mm
Gross Weight	11.58 kg (25.53 lb)
Net Weight	7.82 kg (17.24 lb)
Certifications	CE: EN 60601-1-2:2015 + A1:2021 (V4.1), EN 60601-1:2007/A1:2013/A2:2021 (V3.2) FCC: Part 15 Subpart B / Part 18 Subpart C

Ordering Information

MEDDP-727HPN-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, P-Cap, white

MEDDP-727HNN-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, glass, white

MEDDP-727TND-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, glass, DICOM, white

MEDDP-727TPD-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, P-Cap, DICOM, white

To contact Micromax about Onyx 27" Slim 4k Medical Display | MEDDP-727 use Get a quote.

Features

27" LCD panel with 3840 x 2160 resolution
High brightness 500 nits
Compact and slim design
DVI-D x 1, HDMI 2.0 x 1, DP 1.2 x 1, VGA x 1, HD-SDI in x 1 and out x 1
True flat screen with capacitive touch
10W built-in speaker x 2
Physical OSD key button
Supports optional RFID, camera and DICOM
8MP camera and microphone (optional)

Specifications

Display
Size	27"
Resolution	UHD 3840 x 2160
Max. Colors	1.07B colours
White Luminance (typ.)	500 nits
Viewing Angle (CR=10) (typ.)	178° (H) / 178° (V)
Contrast Ratio (typ.)	1000:1
Touch Screen	Projected capacitive multi-touch screen
Power Requirement	External power adapter, AC in 100~240V, DC 12V / 7.5A
System
OS Support	Windows® 10, Windows® 11
I/O
Input Signal	DVI-D x 1, HDMI 2.0 x 1, DP 1.2 x 1, VGA x 1, HD-SDI x 1
Output Signal	HD-SDI x 1
USB Port	USB 3.0 Type B x 1 for touch screen USB 3.0 Type A x 1 for USB peripherals
Audio	Line-in x 1
Speaker	Built-in 10W speaker x 2
Mechanical and Environmental
Operating Temperature	5°C ~ 40°C (41°F ~ 104°F)
Storage Temperature	-10°C ~ 60°C (14°F ~ 140°F)
Storage Humidity	10% to 90% RH, non-condensing
VESA	100 x 200 mm, 100 x 100 mm
Dimension (W/H/D)	657 x 400 x 62 mm
Packing Size (W/H/D)	786 x 537 x 232 mm
Gross Weight	11.58 kg (25.53 lb)
Net Weight	7.82 kg (17.24 lb)
Certifications	CE: EN 60601-1-2:2015 + A1:2021 (V4.1), EN 60601-1:2007/A1:2013/A2:2021 (V3.2) FCC: Part 15 Subpart B / Part 18 Subpart C

Ordering Information

MEDDP-727HPN-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, P-Cap, white

MEDDP-727HNN-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, glass, white

MEDDP-727TND-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, glass, DICOM, white

MEDDP-727TPD-A1-1010 - 27" LCD monitor, 500 nits, 1 SDI / 1 DVI / 1 DP / 1 HDMI / 1 VGA, DC 12V adapter, P-Cap, DICOM, white

Read less...

To contact Micromax about Onyx 27" Slim 4k Medical Display | MEDDP-727 use Get a quote.

01-MEDDP-727(0.49MB)

02-MEDDP-727(1.10MB)
