Onyx - 10.1" Rugged Medical Tablet | MD102N

Supplier: Micromax

10.1" Rugged Medical Tablet | MD102N

Introducing the Onyx MD102N 10.1" Rugged Medical Tablet - designed for healthcare professionals. With durability, portability, and advanced features, it enhances patient care in any environment.

Features

Intel® Alder Lake processor
Slim and lightweight design for clinical mobility
Long battery life for intensive care services
Standard USB Type-A for easy connection to medical devices
IP54 certified and 1.5 metre drop resistant
ORION client compatible
VESA mounting via adapter
EN60601-1 certified
Ergonomic design adapted for portable and cart use
Windows 10 / Windows 11 IoT

Specifications

Main Specifications
Processor	Intel® Alder Lake N200 1.80GHz
System Memory	DDR5 8GB
OS Support	Microsoft® Windows® 10 IoT LTSB / Windows® 11 IoT / Linux Ubuntu
Storage	NVMe 256GB
Wireless Communication	802.11 ax/a/b/g/n + BT 5.2
Camera	2MP (front) / 8MP (rear)
Touchscreen	Projected capacitive touchscreen with Gorilla Glass 3
Accelerometer Sensor	LSM6DSO
Ambient Light Sensor	LSM6DSO
Controls and Indicators	Power button x 1, volume keys x 2, alarm light x 1 (optional), battery light x 1
Speakers	2W x 2, SPL 98±3dB
Internal Mic	x 1
Power Requirement	DC 15V (60W)
Display
Display Size	10.1" 16:10 wide screen LED panel
Resolution	1920 x 1200
Max. Colors	16.7M
Contrast Ratio	800:1
Luminance (cd/m²)	380 nits
I/O
USB	USB 3.0 (Type-A) x 1, USB 3.0 (Type-C) x 1 (host + display)
Audio Out / Mic In	3.5mm combo audio jack x 1
Video Out	Via USB 3.0 Type-C
DC-in	x 1
Battery Pack
Battery Type	Li-ion
Battery Capacity	9060 mAh (65.2Wh)
Battery Run Time	Approx. 8 hrs
Mechanical and Environmental
VESA	VESA 75 via rear cover bracket (with / without) 2 design
Degree of Protection	IP54
Operating Temperature	0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature	-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity	10%~95% @ 40°C, non-condensing
Net Weight	Approx. 1.2 kg
Certifications	CE: EN 60601-1-2:2020 (V4.1), EN 60601-1:2006/A1:2020 (V3.2) FCC: Part 18 Class B, Part 15 C/E UL: ANSI AAMI ES60601-1:2005/A1:2012/A2:2021 (V3.2) cUL: CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020, MOD) (V3.2)

Ordering Information

ONYX-MD102N-P1-A1-0002 - Tablet, N200, 10.1" FHD, battery, C-TS (G), 8GB RAM, 256GB NVMe, front/rear camera, WiFi/BT, WOHD

ONYX-MD102N-P1-A1-0003 - Tablet, N200, 10.1" FHD, battery, C-TS (G), 8GB RAM, 256GB NVMe, front/rear camera, WiFi/BT, WOHD (TL)

Optional Accessories

125530065E - Medical power adaptor, AC/DC 100~240V, 15V / 4.34A / 65.1W

To contact Micromax about Onyx 10.1" Rugged Medical Tablet | MD102N use Get a quote.
