Name: Radiography System | 5000 F — DuraDiagnost Rel 4
Price: 300000 AUD
Availability: InStock

Rapid, high-quality digital radiography with streamlined automated workflow.

Product Features

Designed for fast, smooth patient examinations and reliable imaging services in healthcare settings.
Flexible solution for both low and high acuity environments with digital wireless and fixed flat detectors.
Premium Cesium Iodide (CsI) technology ensures consistently high-quality digital images.

Key Features & Benefits

Eleva Workspot Efficiency: Intuitive harmonised touch-screen interface with pre-settings & custom profiles for automated workflow. Images appear on screen within seconds for greater throughput.
Lightweight Wireless Detectors: Offers easy positioning, portability, and reliable performance wherever needed, meeting industry standards for weight and durability.
Wide Application: Compatible with both stationary (wall/table) and portable operation, providing flexibility for diagnostic needs.

Technical Specifications

Component	Specification
X-ray Generator	50 kW / 65 kW, 400/480V (±10%), 50/60 Hz, 3-phase, 112–134A, Max tube voltage 150 kV
Collimator	Manual, light field indicator, 30s timer, ±45° angle
X-ray Tube	RO1750/SRO 33100, 13° anode angle, 150 kV max, 220 kJ anode capacity
Wireless Portable Detector	CsI, 35 x 43 cm, 148–160µm pixel, 5.7–6.6MP, 2.8–3.1kg, up to 16 bit A/D conversion
Fixed Detector	CsI, 43 x 43 cm, 8.2MP, 148µm pixel, 2.1kg
Eleva Workspot Computer	480 GB SSD, 16 GB RAM
X-ray Tube Floor Stand	233.25 cm height, vertical lift max 150 cm, source–image distance 110–250 cm, tube rotations up to ±180°

To contact Philips Healthcare about Philips Radiography System | 5000 F — DuraDiagnost Rel 4 use Get a quote.
