Philips - Image Guided Therapy System | Azurion 7 M20 with FlexArm

Supplier: Philips Healthcare

Image Guided Therapy System | Azurion 7 M20 with FlexArm

The Azurion 7 M20 with FlexArm is an advanced image-guided therapy system designed for exceptional imaging flexibility and superior clinical care in medical environments.

Virtually unlimited imaging flexibility with eight-axis FlexArm for optimal clinical performance.

Key Features

Ceiling-mounted monoplane image-guided therapy system.
Eight-axis FlexArm allows virtually unlimited imaging flexibility and improved team positioning without disturbing the patient or equipment setup.
Axsys intelligent motion control system for more independent and intuitive table-side control.
Seamless control of all relevant applications from a single touch screen at the table side for fast and informed decision-making.
Enhanced C-arm design maintains image beam alignment with the patient for optimal visualisation during 2D and 3D procedures.

Specifications

C-arm Z rotation	-135° to +135°
C-arm rotation (head-end)	120° LAO, 185° RAO
C-arm rotation (side position)	90° LAO, 90° RAO
C-arm angulation (head-end)	90° cranial, 90° caudal
C-arm angulation (side position)	185° cranial, 120° caudal
C-arm rotation/angulation speed	up to 25°/sec (normal) or up to 55°/sec (Rotational Angiography)
Longitudinal movement	Up to 6.35 m
Lateral movement	2.36 m
C-arm depth	0.9 m
Focal spot to isocentre	0.81 m
Isocentre-to-floor distance	1.065 m
Source-to-image distance	0.895 – 1.195 m
Installation height	2.7 m or 2.9 m
Table height (min./max.)	0.74 – 1.02 m
Tabletop length (with OR rail)	3.19 m
Tabletop width	0.5 m
Max. table load	325 kg
Max. patient weight	250 kg

Key Features

Ceiling-mounted monoplane image-guided therapy system.
Eight-axis FlexArm allows virtually unlimited imaging flexibility and improved team positioning without disturbing the patient or equipment setup.
Axsys intelligent motion control system for more independent and intuitive table-side control.
Seamless control of all relevant applications from a single touch screen at the table side for fast and informed decision-making.
Enhanced C-arm design maintains image beam alignment with the patient for optimal visualisation during 2D and 3D procedures.

Specifications

C-arm Z rotation	-135° to +135°
C-arm rotation (head-end)	120° LAO, 185° RAO
C-arm rotation (side position)	90° LAO, 90° RAO
C-arm angulation (head-end)	90° cranial, 90° caudal
C-arm angulation (side position)	185° cranial, 120° caudal
C-arm rotation/angulation speed	up to 25°/sec (normal) or up to 55°/sec (Rotational Angiography)
Longitudinal movement	Up to 6.35 m
Lateral movement	2.36 m
C-arm depth	0.9 m
Focal spot to isocentre	0.81 m
Isocentre-to-floor distance	1.065 m
Source-to-image distance	0.895 – 1.195 m
Installation height	2.7 m or 2.9 m
Table height (min./max.)	0.74 – 1.02 m
Tabletop length (with OR rail)	3.19 m
Tabletop width	0.5 m
Max. table load	325 kg
Max. patient weight	250 kg

Read less...

To contact Philips Healthcare about Philips Image Guided Therapy System | Azurion 7 M20 with FlexArm use Get a quote.

Azurion environmental performance overview(0.33MB)

Azurion accessoires brochure(5.19MB)
