High precision five-axis milling for complex dental implants and restorations.

The AMM-580 is a highly versatile and precise milling machine created to meet demanding dental implant requirements. It is engineered for processing implant bars, screw-retained bridges, customised abutments, and more, delivering exceptional machining stability and accuracy.

Key Parameters

Number of Axis	Five axis
Processing Types	Crown/Bridge, Implant bar, Screw-retained bridge, Abutment, Locator
Milling Mode	Wet/Dry
Millable Material	Titanium disc, Cobalt Chrome, Premill, Glass ceramic, PEEK, PMMA
Material Thickness	10–25 mm
Fixture	98 mm/Block
Repeat Positioning Accuracy	±5 µm
Linear Drive System	High precision linear guide slide block
Rotary Drive System	High precision reducer
External Dimensions	750 × 885 × 1663 mm
Weight	500 kg
Tool Changer	25 tools
Stroke	X,Y,Z axis: 320 × 120 × 130 mm, A-axis: 360°, B-axis: -110° to +30°
Spindle	Power: 2.5 kW, Cooling: Water, Speed: 60,000 rpm, Chuck size: 6 mm
Input Power Supply	AC220V, 50/60 Hz, Power: 3.8 kW
Air Pressure	0.6–0.8 MPa

Main Features

Supports both wet and dry milling for a broad range of dental materials.
Stable structure assures precision and durability for intensive dental workflows.
Advanced five-axis design allows for complex implant cases and multi-unit bridges.
Automatic tool changer can handle up to 25 tools for uninterrupted operations.
High precision linear and rotary drives for repeatable, accurate results.

To contact Aidite about Aidite Dental Milling Machine | AMM-580 use Get a quote.

Key Parameters

Number of Axis	Five axis
Processing Types	Crown/Bridge, Implant bar, Screw-retained bridge, Abutment, Locator
Milling Mode	Wet/Dry
Millable Material	Titanium disc, Cobalt Chrome, Premill, Glass ceramic, PEEK, PMMA
Material Thickness	10–25 mm
Fixture	98 mm/Block
Repeat Positioning Accuracy	±5 µm
Linear Drive System	High precision linear guide slide block
Rotary Drive System	High precision reducer
External Dimensions	750 × 885 × 1663 mm
Weight	500 kg
Tool Changer	25 tools
Stroke	X,Y,Z axis: 320 × 120 × 130 mm, A-axis: 360°, B-axis: -110° to +30°
Spindle	Power: 2.5 kW, Cooling: Water, Speed: 60,000 rpm, Chuck size: 6 mm
Input Power Supply	AC220V, 50/60 Hz, Power: 3.8 kW
Air Pressure	0.6–0.8 MPa

Main Features

Supports both wet and dry milling for a broad range of dental materials.
Stable structure assures precision and durability for intensive dental workflows.
Advanced five-axis design allows for complex implant cases and multi-unit bridges.
Automatic tool changer can handle up to 25 tools for uninterrupted operations.
High precision linear and rotary drives for repeatable, accurate results.
